U-Shape Office Cubicle Space Planning & Layout Plan (CS-2857)

A U-shape workstation wraps three surfaces around the user. This cubicle layout shows how U-shape stations can be set out where people juggle paperwork, multiple monitors and reference material at once.

Nothing here is fixed. Workstation dimensions, panel heights, glazing, fabric and laminate finishes are chosen per project — 5×5 and 6×6 cubicles are the most common starting points, adjusted to suit the floor plate.

Aisle widths are set for comfortable two-way circulation and to keep clear routes to exits, which matters as soon as the seat count climbs.

Best suited to supervisors, design and engineering staff, accounts teams and anyone working across several surfaces at once.

Cubicles Shop manufactures direct, with over 25 years of architectural and office furniture experience behind every plan. Space planning and layout design are $500, credited in full to your order — send us your floor dimensions and we will draw your space.
