U-Shape Workstation Floor Plan & Cubicle Dimensions (CS-2849)

A U-shape workstation wraps three surfaces around the user. This cubicle layout shows how U-shape stations can be set out where people juggle paperwork, multiple monitors and reference material at once.

Sizes shown are a starting point, not a constraint. We regularly adapt layouts to 5×5, 6×6, 4×2 and custom workstation footprints, with panel heights set to match the privacy level each team needs.

Shared equipment — printers, plotters, supply storage — is positioned so no desk sits directly beside a high-traffic machine.

Best suited to supervisors, design and engineering staff, accounts teams and anyone working across several surfaces at once.

Every order includes space planning. Cubicles Shop supplies new, manufacturer-direct office cubicles and modular workstations across the United States, drawing each layout to the customer’s own floor dimensions.
