CAD Office Cubicle Floor Plan & Cubicle Dimensions (CS-2745)

This is a CAD-drawn office cubicle floor plan, dimensioned and drawn to scale. It shows panel runs, workstation footprints and circulation in the form a contractor or facilities team can work from directly.

The plan is adaptable. Workstation size, panel height, glazed or fabric panels and storage are all specified per order, so the same arrangement can be built at a range of footprints and budgets.

Panel glazing is used selectively in this plan — clear or frosted tops where light needs to travel, solid fabric where acoustic separation matters more.

Best suited to contractors, architects, facilities managers and anyone who needs a dimensioned drawing rather than a concept sketch.

We are a manufacturer-direct supplier of office cubicles, modular workstations and call center cubicles. Layout design and space planning come free with your order — share your floor plan and we will work to it.
