Private Office Cubicle Layout & Floor Plan Design (CS-2800)

Some roles need walls. This private office cubicle layout shows enclosed and high-panel workstations placed for confidentiality and quiet, while staying part of the wider floor plan rather than cut off from it.

Panel heights, workstation sizes and finishes are all configurable. Common footprints include 5×5, 6×6 and 4×2 workstations, with panel heights typically between 51 and 66 inches depending on how much privacy and acoustic separation the space needs.

Power and data routing is planned with the layout, not after it — panel raceways carry cabling to each workstation so there are no trailing leads across walkways.

Best suited to managers, HR, legal, finance and any role handling confidential conversations or sensitive documents.

Cubicles Shop manufactures direct, with over 25 years of architectural and office furniture experience behind every plan. Space planning and layout design are $500, credited in full to your order — send us your floor dimensions and we will draw your space.
